Egr valve clicking on and off repeatedly	Please Register to enjoy additional Member Benefits

Author

Post

vincentfishing United Kingdom

Tue May 13 2025, 03:38pm

Member No: #57297

Joined: Nov 26 2020
Location: Westgate kent uk

Hi , pretty sure egr valve is caput, but before I find another I wanted to check everything is OK at connector plug ,to avoid disturbing ecu yet again (only recently cleared communication fault ) I unplugged egr and tested voltages across 5 pins , see attached Pic, could anyone tell me if these are the voltages I should expect to see and if so would this confirm it's egr faulty and not wiring. Thanks
